Specialised Vessel Services

SVS Cornwallis

Fast Support Intervention / Multi Purpose Vessel / Guard Ship

Main Particulars

Length

53.25 m

Moulded Beam

10.20 m

Draft

3.20 m

Gross Tonnage

439 T

Net Tonnage

132 T

Deck Area

240 m²

Max. Deck Load

2.5 T/m²

Performance

Cruise Speed

11.5 Knots

Maximum Speed

21 Knots

Range

6000 NM

Endurance

35 Days

Capacities

Fuel Capacity

169.85 m³

Potable Water Capacity

28.60 m³

Water Maker

Sea recovery Aqua whisper producing 2.5 m³ per day

Fresh Water / Cargo

173.10 m³

Deck Cargo

250 T

Accommodation

Crew

8

Charterers

4

Business Class Seats

80

Air Conditioning

Yes

Classification

Class

Bureau Veritas

Vessel Type

Fast Utility Vessel

Built

2013

Ship Builder

DAMEN Netherlands

Flag

St Vincent & the Grenadines

Port of Registry

Kingstown

Official Number

11381

IMO Number

9650561

Call Sign

J8B4908

Navigation Equipment

Radar

2x JRC, JMA 5212-4 HSB

Searchlight

2x 1000W MP Pesch

Auto Pilot

Alphaseapilot MFC

Echo sounder

Alphatron, Alphadepth DT800

Magnetic compass

Richie – Navigator HB-71

Satellite navigation(GPS)

Veripos / JLR 7800

Gyro Compass

Alphaminicourse

Dynamic Positioning (DP)

Alphatron / Navis,
(Dynapos AM)

Life Saving Equipment

Lifebuoys

6

Lifejackets

88

Life Rafts

Inflatable life rafts for min. 88 persons

EPIRB

McMurdo E5

SART

McMurdo - 54 Rescue

Fire Fighting Internal

Novec 1230

Communication Equipment

SSB radio

Sailor 6000

VHF radio

2 x Sailor RT6222

Navtex & AIS

JRC, NCR-333 & JRC, JHS-182

Email/Sat phone equipment

VSAT/IOP

Tracking device

Sat C

Machinery

Main Engines

4x Caterpillar 3512C TA
(4472 kW)

Generators

3x Caterpillar C4.4, 99 kW each

Propulsion

4x Fixed pitch propellers

Bowthrusters

2x 85 bkW, electrically driven

Marine Deck Crane

HLM 25-4S SWL 1450kg @ 12.62m

Fire Safety Equipment

Safety Equipment as per SOLAS, Flag and Class Society requirement.

SVS Cornwallis Gallery

SVS Cornwallis GA Plans
